Portable Loading Dock Ramp / Yard Ramp - 18,000 LB Capacity
This heavy-duty portable loading dock ramp (yard ramp) is engineered for safe and efficient loading/unloading of trucks, trailers, and shipping containers without a permanent dock. With a 18,000 lb weight capacity, it is a versatile solution for warehouses, distribution centers, construction sites, and industrial yards needing flexible material handling.
| Specification | Details |
|---|---|
| Maximum Load Capacity | 18,000 Pounds (8,165 kg) - Dynamic & Static Load Certified |
| Overall Dimensions | Length: 30ft (9.14m) | Width: 8ft (2.44m) | Adjustable Height: 36" - 60" (91cm - 152cm) |
| Main Material | 10GA/12GA Heavy-Duty Carbon Steel with Anti-Rust Coating |
| Surface Texture | Serrated Steel Grating (Non-Slip) - Ideal for Wet/Oily Surfaces |
| Mobility Components | 10" Heavy-Duty Pneumatic Wheels + Tow Bar for Easy Relocation |
| Height Adjustment | Manual Hydraulic Hand Pump with Safety Lock Pins |
| Safety Features | 6" High Side Curbs, Safety Chains, Hydraulic Lock Valve, Anti-Tip Stabilizers |
| Ramp Self-Weight | Approx. 4,500 lbs (2,041 kg) |
| Compatibility | Forklifts, Pallet Jacks, Light/Medium Duty Commercial Trucks |
| Operating Temperature Range | -20°F to 120°F (-29°C to 49°C) |
This portable yard ramp eliminates the need for permanent loading docks, offering a cost-effective and flexible solution for businesses with variable loading/unloading locations. Its rugged steel construction and safety enhancements ensure long-lasting performance in harsh industrial environments.
